3-8 Handling and Maintenance Rev. A
Notes:
❏
Personal check is ejected in the forward direction only.
❏
The paper roll must be loaded onto both the receipt and journal sides correctly before selecting MICR
function by transmitting FS a 0. Otherwise, check paper is not fed properly.
❏
The check waiting state is canceled using DLE ENQ 3.
❏
After the personal check is ejected, the SLIP LED indicator lights and the printer does not proceed to
the next operation until the check is removed.
❏
The check waiting time and the interval from when a check is inserted to when the operation starts can
be set using ESC f.
❏
To check the MICR function status exactly, DLE EOT BS 1 should be used.
Installing and Removing the Ribbon Cassette
Installing the Ribbon Cassette
1. Open the printer cover.
2. Turn the ribbon cassette’s knob in the direction of the arrow, to take up any slack in the
ribbon.
3. Insert the ribbon cassette in the printer and rotate the cassette’s knob five or six more times.
This is necessary to place the ribbon in the correct position.
Notes:
❏
Make sure that the ribbon is installed in front of the print head without wrinkles or creases. If it is
hard to see, open the print head cover.
❏
Never turn the ribbon cassette’s feed knob in the opposite direction of the arrow marked on the
cassette.
Figure 3-11. Installing the Ribbon Cassette
Knob
CONFIDENTIAL
