Epson TM-U950 Technical Manual

3-10 Handling and Maintenance Rev. A
Mounting the Power Switch Cover
To guard the power switch from incorrect operation, attach the power switch cover on the
printer power switch as shown in Figure 3-14.
Journal Lock Key Handling
The journal lock is located inside the printer cover as shown in Figure 3-15. The lock is closed
when the key is turned to the right. The lock is open when the key is turned to the left.
Note:
Make sure that you remove the key from the lock before you close the printer cover, otherwise the printer
cover may be damaged.
Removing the Jammed Paper
To clear a paper jam inside the printer, follow the steps below:
1. Turn the printer off and open the printer cover.
2. If the paper is jammed in the journal paper side, cut the journal paper with a pair of scissors
or a knife referring to Figure 3-7; then remove the take-up spool.
Figure 3-14. Installing the Power Switch Cover
Figure 3-15. Using the Journal Lock Key
Journal lock key
CONFIDENTIAL

Epson TM-U950 Specifications

General

Print speed	18.6 ips
Character size	1.3 x 3.1 mm
Print technology	Dot matrix
Paper dimensions	210 x 297 mm
Dimensions (WxDxH)	251 x 298 x 194.5 mm
Electromagnetic compatibility	VCCI, FCC, CE
Safety	UL, CSA
Country of origin	China
Mean time between failures (MTBF)	180000 h
Serial interface	Yes
Standard interfaces	RS-232C
Weight (imperial)	12.3 lbs
Pallet width	1200 mm
Pallet height	1000 mm
Pallet length (UK)	2250 mm
Quantity per pallet	24 pc(s)
Quantity per pallet (UK)	36 pc(s)
Quantity per pallet layer	4 pc(s)
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	6 pc(s)
Package depth	425 mm
Package width	360 mm
Package height	330 mm
Package weight	7196 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	298 mm
Width	186 mm
Height	195 mm
