Epson TM-U950 Technical Manual

Rev. A Handling and Maintenance 3-9
TM-U950/U950P Technical Manual
Removing the Ribbon Cassette
To remove the ribbon cassette, grasp the ribbon cassette’s tab and pull it out of the printer.
Inserting the Stamp Set
If your printer has the stamping feature, follow the steps below to install the stamp set in the
printer.
1. Open the printer cover.
2. Insert the stamp set into the printer as shown in the figure below. Then close the printer
cover.
Note:
To remove the stamp set, pull it out of the printer in the opposite direction of the arrow in the figure above.
Figure 3-12. Removing the Ribbon Cassette
Figure 3-13. Installing the Stamp Set
Printer cover
Stamp set
CONFIDENTIAL

Epson TM-U950 Specifications

General

Print speed	18.6 ips
Character size	1.3 x 3.1 mm
Print technology	Dot matrix
Paper dimensions	210 x 297 mm
Dimensions (WxDxH)	251 x 298 x 194.5 mm
Electromagnetic compatibility	VCCI, FCC, CE
Safety	UL, CSA
Country of origin	China
Mean time between failures (MTBF)	180000 h
Serial interface	Yes
Standard interfaces	RS-232C
Weight (imperial)	12.3 lbs
Pallet width	1200 mm
Pallet height	1000 mm
Pallet length (UK)	2250 mm
Quantity per pallet	24 pc(s)
Quantity per pallet (UK)	36 pc(s)
Quantity per pallet layer	4 pc(s)
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	6 pc(s)
Package depth	425 mm
Package width	360 mm
Package height	330 mm
Package weight	7196 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	298 mm
Width	186 mm
Height	195 mm
