Epson TM-U950 Technical Manual

Rev. A Disassembly, Assembly, and Adjustments 5-1
TM-U950/U950P Technical Manual
Chapter 5
Disassembly, Assembly, and Adjustments
Small Part Specifications
This section uses abbreviations for small parts such as screws and washers. The following tables
list these abbreviations as well as E-type retaining ring sizes.
Actual Size E-type Retaining Rings
Small Part Abbreviations
CB : Cross-recessed Binding head screw
CC : Cross-recessed Cup head screw
CP : Cross-recessed Pan head screw
CP (P4) : Cross-recessed Pan head screw with Plane washer 4
CP (S. P1) : Cross-recessed Pan head S2W1
CBB-tite : Cross-recessed Binding head B-tite self-tapping screw
CBT-B : Cross-recessed Binding head self-tapping screw without fluted class 2
CCS-tite : Cross-recessed Cup head S-tite self-tapping screw
CCS-tite F : Cross-recessed Cup head S-tite self-tapping screw with flat end
CPS-tite : Cross-recessed Pan head S-tite self-tapping screw
CPS-tite (O) : Cross-recessed Pan head S-tite self-tapping screw with Outside toothed lock washer
CPS-tite (P2) “ Cross-recessed Pan head S-tite self-tapping screw with Plane washer 2
CPS-tite (P4) : Cross-recessed Pan head S-tite self-tapping screw with Plane washer 4
CPP-tite : Cross-recessed Pan head P-tite self-tapping screw
CPT-B : Cross-recessed Pan head self-tapping screw without fluted class 2
CPB-tite (P2) : Cross-recessed Pan head B-tite self-tapping screw with Plane washer 2
RE : Retaining ring E-type
HL : Hexagon Lock screw
PW : Plane Washer
CONFIDENTIAL

Epson TM-U950 Specifications

General

Print speed	18.6 ips
Character size	1.3 x 3.1 mm
Print technology	Dot matrix
Paper dimensions	210 x 297 mm
Dimensions (WxDxH)	251 x 298 x 194.5 mm
Electromagnetic compatibility	VCCI, FCC, CE
Safety	UL, CSA
Country of origin	China
Mean time between failures (MTBF)	180000 h
Serial interface	Yes
Standard interfaces	RS-232C
Weight (imperial)	12.3 lbs
Pallet width	1200 mm
Pallet height	1000 mm
Pallet length (UK)	2250 mm
Quantity per pallet	24 pc(s)
Quantity per pallet (UK)	36 pc(s)
Quantity per pallet layer	4 pc(s)
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	6 pc(s)
Package depth	425 mm
Package width	360 mm
Package height	330 mm
Package weight	7196 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	298 mm
Width	186 mm
Height	195 mm
