5-2 Disassembly, Assembly, and Adjustments Rev. A
Screw Types
Disassembly
This section describes disassembly procedures for replacing the following two parts:
❏ Print head unit
❏ Cutter blade
For other disassembly procedures, see Printer Mechanism Assembly and Whole Unit Assembly
in this chapter. The disassembly procedures are basically the reverse of the assembly steps
described in these sections.
Head (top) Head (side) Body Washer (assembled)
