Epson TM-U950 Technical Manual

5-6 Disassembly, Assembly, and Adjustments Rev. A
Printer Mechanism Unit Assembly
The assembly process is divided into sub-assembly and main assembly.
Perform the sub-assembly first to construct each unit from the parts. Then proceed to the main
assembly.
When assembling the printer, check each part and its attachment position by referring to the
exploded diagrams in Chapter 6.
An asterisk after a step number (such as 2.*) indicates that lubrication must be performed.
Lubricants should be applied when assembling the parts, since it is difficult to do so afterwards.
Perform lubrication by referring to the lubrication section at the end of Chapter 6.
For adjustments, follow the descriptions in the Adjustments sections in this chapter. Whenever
disassembly is performed even for just one part, check whether adjustment is necessary before
assembly.
All illustrations show the printer with a MICR reader installed, unless marked “Without MICR
reader.”
CONFIDENTIAL

Epson TM-U950 Specifications

General

Print speed	18.6 ips
Character size	1.3 x 3.1 mm
Print technology	Dot matrix
Paper dimensions	210 x 297 mm
Dimensions (WxDxH)	251 x 298 x 194.5 mm
Electromagnetic compatibility	VCCI, FCC, CE
Safety	UL, CSA
Country of origin	China
Mean time between failures (MTBF)	180000 h
Serial interface	Yes
Standard interfaces	RS-232C
Weight (imperial)	12.3 lbs
Pallet width	1200 mm
Pallet height	1000 mm
Pallet length (UK)	2250 mm
Quantity per pallet	24 pc(s)
Quantity per pallet (UK)	36 pc(s)
Quantity per pallet layer	4 pc(s)
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	6 pc(s)
Package depth	425 mm
Package width	360 mm
Package height	330 mm
Package weight	7196 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	298 mm
Width	186 mm
Height	195 mm
