Rev. A Disassembly, Assembly, and Adjustments 5-69
TM-U950/U950P Technical Manual
Sub-assembly D: Cover Paper Take-up
1. Attach the cover-paper take-up to the frame-paper take-up assembly on the printer
mechanism assembly.
Frame-paper take-up assembly
Printer mechanism assembly
CONFIDENTIAL
To Next Page
