Epson TM-U950 Technical Manual

5-82 Disassembly, Assembly, and Adjustments Rev. A
Note:
During the special setting mode, the printer checks several times that DIP switch 2-6 is off. If the
switch is on, the printer prints the following message and ends special setting mode.
7
Is the measure value correct?
Confirms if the measured detection value is correct,
and prints message as follows depending on the
result:
When the value is correct:
There might have been some mistakes of user
operation. Go to step 1 and execute the
adjustment again. Replace the detector-slip
insertion assembly if this error message is still printed
after executing the adjustment two times.
8
Find and set threshold value
Calculates and sets the threshold value for both
cases of with and without paper using the detected
values. The threshold value set is printed as follows:
9
Write threshold value in EEPROM
Prints the following message.
Remove the slip paper from the printer
This is an unrecoverable error. Reset the printer and
confirm if the initialization is executed correctly.
Replace the main circuit board if this error message
is still printed after executing the adjustment a
couple of times.
10
End special setting mode
Prints the following message and ends special
setting mode. The printer automatically enters
printing mode when special setting mode is
finished.
Set DIP switch 6 of the switch bank 2 to off after the
message is printed.
Step Printer Operation User Operation
(6) The measured value is available.
When the value is not correct:
(6) The measured value is NOT AVAILABLE.
Special setting mode is finished.
(7) Threshold value : [ ** ]
(** shows threshold value in hexadecimal.)
(8) Please REMOVE paper
for writing value into the EEPROM
Writes the threshold value in EEPROM when the slip
paper is removed. Confirms whether the value is
written correctly, and prints the following message
depending on the result.
When the value is written correctly:
(9) Writing is completed.
Threshold value : [ ** ]
When the value is written correctly:
(** shows threshold value in hexadecimal.)
(9) EEPROM Write ERROR!!
EEPROM process STOP.
Please turn ON DIP SW 2-6.
Special setting mode is finished.
EEPROM is write-protected!!
Special setting mode is finished.
CONFIDENTIAL

Epson TM-U950 Specifications

General

Print speed	18.6 ips
Character size	1.3 x 3.1 mm
Print technology	Dot matrix
Paper dimensions	210 x 297 mm
Dimensions (WxDxH)	251 x 298 x 194.5 mm
Electromagnetic compatibility	VCCI, FCC, CE
Safety	UL, CSA
Country of origin	China
Mean time between failures (MTBF)	180000 h
Serial interface	Yes
Standard interfaces	RS-232C
Weight (imperial)	12.3 lbs
Pallet width	1200 mm
Pallet height	1000 mm
Pallet length (UK)	2250 mm
Quantity per pallet	24 pc(s)
Quantity per pallet (UK)	36 pc(s)
Quantity per pallet layer	4 pc(s)
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	6 pc(s)
Package depth	425 mm
Package width	360 mm
Package height	330 mm
Package weight	7196 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	298 mm
Width	186 mm
Height	195 mm
