Epson TM-U950 Technical Manual

Rev. A iii
TM-U950/TM-U950P Technical Manual
About This Manual
❏
Chapter 1 provides general specifications and hardware configuration information.
❏
Chapter 2 provides general operating principles and printer mechanism configuration
information.
❏
Chapter 3 provides handling and maintenance information.
❏
Chapter 4 provides troubleshooting information.
❏
Chapter 5 provides printer disassembly, assembly, and adjustment instructions.
❏
Chapter 6 (Appendix) provides circuit board and exploded diagrams.
Notes and Cautions
Note:
Notes have important information and useful tips on the operation of your printer.
CAUTION:
Cautions must be observed to avoid damage to your equipment.
CONFIDENTIAL

Epson TM-U950 Specifications

General

Print speed	18.6 ips
Character size	1.3 x 3.1 mm
Print technology	Dot matrix
Paper dimensions	210 x 297 mm
Dimensions (WxDxH)	251 x 298 x 194.5 mm
Electromagnetic compatibility	VCCI, FCC, CE
Safety	UL, CSA
Country of origin	China
Mean time between failures (MTBF)	180000 h
Serial interface	Yes
Standard interfaces	RS-232C
Weight (imperial)	12.3 lbs
Pallet width	1200 mm
Pallet height	1000 mm
Pallet length (UK)	2250 mm
Quantity per pallet	24 pc(s)
Quantity per pallet (UK)	36 pc(s)
Quantity per pallet layer	4 pc(s)
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	6 pc(s)
Package depth	425 mm
Package width	360 mm
Package height	330 mm
Package weight	7196 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	298 mm
Width	186 mm
Height	195 mm
