EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Disassembly/assembly Disassembly/Reassembly Procedures 294
Confidential
DISASSEMBLY FLOWCHART
A1
C1
B1
D1
Start
Rear Cover (Back)
(→P. 296)
ASF Front Cover
(→P. 297)
Housing Upper
(→P. 299)
Housing Left
(→P. 298)
Cable Guide
(→P. 300)
Hinge Lower Cover
(→P. 299)
Ink Eject Cover
(→P. 297)
Housing Right
(→P. 298)
Start
Peel off the CRCM FFC
(→P. 301)
Plate
(→P. 301)
Guide Cover
(→P. 302)
RIPS Unit
(→P. 302)
Ink Supply Unit
(→P. 304)
Pressing Plate
(→P. 305)
A2
C2
B2
D2
A3
C3
B3
D3
A4
C4
B4
D4
A5
C5
B5
D5
A6
C6
B6
D6
A7
C7
B7
D7
A8
C8
B8
D8
A9
C9
B9
D9
A10
C10
B10
D10
A11
C11
B11
D11
A12
C12
B12
D12
A13
C13
B13
D13
A14
C14
B14
D14
A15
C15
B15
D15
Upper Plate
(→P. 305)
Cartridge Detection Sensor
Board(→P. 308)
D16
a
a
D17
CSIC Board
(→P. 308)
A16
Decompression Pump Assy
(→P. 306)
C16
Ink Sensor YMCBk
(→P. 307)
B16
CSIC Board FFC
(→P. 306)
C H E C K
P O I N T
 As for the procedure indicated by , refer to 6.2.4.4
Housing (WF-C5200 Series) (2) (p. 254) in the case of
the WF-C5200 Series, and remove the parts from the
Rear Back Cover to the Housing Top.
 The procedure indicated by is applicable only in the
WF-C5700 Series/ET-8700.
 Implement the procedure indicated by when
removing the Ink Tube from the RIPS Unit and
Printhead.
Preparation for
Dissembling
Ink Discharge
(→P. 295)
