About this Manual
Paraquda Startup & Safety © Essemtec AG
xi
0000003/11 / November 4, 2014
Text Box
Meaning of pictogram: a value (alphanumeric) has to be entered by means of the on-screen
keyboard, after clicking the text box (usually a parameter). The pictogram is placed next to the
corresponding parameter name.
Example:
Barcode, enter the barcode of the feeder.
Drop Down List
Meaning of pictogram: one of the presented items on the drop down list has to be selected, after
clicking the box (usually a parameter). The pictogram is placed next to the corresponding
parameter name.
Example:
No of pick retries, select the desired number of pick retries.
Text Conventions and their Meanings
Various text styles are used in this Startup & Safety Manual manual in order to support the
readability of the text or to emphasize the meaning of text segments.
Parameters and
actual Values
Machine parameters and actual values are
visualized by bold characters and in the same
spelling as in the menu. Also the state of the
parameter is written in the same way.
Set the parameter
Optimization mode to
Maximum performance
Pickup 5 [ms]
Soft Key Context sensitive function keys are written in
italic and bold. Normally they are shown
together with the respective pictogram.
Press New to create a new
light profile
Menu Key
(Screen)
Starts a submenu. Same style as the Soft Keys.
Production Settings
Check Boxes Are located anywhere on a screen. They have
same style as Soft Keys.
Select Setup check
Menu Tree In a text flow the hierarchy of a menu is visu-
alized by using hyphens and bold characters.
Setup - Optimization -
Recipe Splitting
Screen Screens are written in bold using capital and
small letters.
... on Produce screen
Cross
Reference
Written in blue italic.
see page Fehler! Es wurde
kein Textmarkenname
vergeben.
