Essemtec Paraquda - Vision

Equipment Overview
2-16 © Essemtec AG Paraquda Startup & Safety
0000003/11 / November 4, 2014
Z Elements
The Z elements consist of the
Z axis.
Depending on the machine configuration, the
Paraquda can have a total of 4 independent Z
elements (4 independent axes for Z
), driven by
servo motors.
2.3.12 Vision
Overview
Two vision systems provide high precision and
fast component pickup and component
placement. The vision is also used for calibration
and other pur
poses.
