Dispense Head
The Dispense Head includes the Z elements (
Z
ZT Elements
The ZT elements consist of
Z and Theta axis.
The Paraquda has a total of 4 independent ZT
elemen
ts (4 independent axes for Z, 4
independent axes for rotation), driven by servo
motors. The rotation axis is also known as the
Theta axis and can rotate a component 360°. The
Z axis has a stroke of 60 mm. Independently
each axis can pick any tool from the
toolchanger.
