Equipment Overview
2-14 © Essemtec AG Paraquda Startup & Safety
0000003/11 / November 4, 2014
Beam
The beam is part of the XY Gantry. It is the
traverse which makes the bridge between the
two Y motors (Y, Y1) and
which builds the X axis
for the head.
P&P Head
The Pick
-&-Place Head includes the top camera
and the ZT elements (
Z and Theta axis).
