Essemtec Paraquda - Danger Zones and Location of Safety Labels

Safety
Paraquda Startup & Safety © Essemtec AG
1-7
0000003/11 / November 4, 2014
1.5.2 Danger Zones and Location of Safety Labels
The danger zones are marked with safety labels on the machine.
Machine Zone left and right
The XY gantry and the head can move
unexpectedly in X, Y and Z direction.
Reaching into the machine can cause severe
injury.
Check that the safety labels indicating 'KEEP
HANDS CLEAR' are properly in place (see
picture). A total of 2 labels are placed on the
cover, one on the left side of the machine, one
on the right side of the machine.
Machine Zone front and rear
The XY gantry and
the head can move
unexpectedly in X, Y and Z direction.
Reaching into the machine can cause severe
injury.
Check that the safety labels indicating 'KEEP
HANDS CLEAR' are properly in place (see
picture). A total of 4 labels are placed on the
Plexiglas co
ver, two on the frontside of the
machine and two on the rear side of the
machine.
