Essemtec Paraquda - Assign Components to the Feeder

Operating of the Machine
4-48 © Essemtec AG Paraquda Startup & Safety
0000003/11 / November 4, 2014
Setup
Job
Processes
A medium has to be assigned to the process.
There is also the possibility to deactivate a
process.
Setup
Job
Save
Load
to load the created job.
Check if all components are set up and
the
progress bar appears green (1). If this is not the
case (not all components kitted), go to the step
"Assign Components to the Feeder" on page
4-
48
.
Check if all media are set up and the progress
bar appears gree
n (1). If this is not the case (not
all media kitted), go to the step "Assign Medium
to the Dispense Valves" on page
4-50.
4.5.2 Assign Components to the Feeder
Optimization
The machine generates a proposal for best
allocation of components to feeder lanes (1) and
best feeder position on feeder racks (2).
Optimization distinguish between best
performance or minimum changeov
er.
Wherever applicable, already kitted components
are leaved as is to keep changeover time as low
as possible. The proposal can be printed and
used as picking list to set up the machine.
Note:
For the optimization only the current job
is taken into acco
unt.
