Human Machine Interface HMI
3-10 © Essemtec AG Paraquda Startup & Safety
0000003/11 / November 4, 2014
1
Title bar The Title Bar displays:
• loaded file (job, recipe, package, component etc.)
• user name
• machine status
2
Tab bar The Tab Bar is part of the navigation. It leads to the main tasks (screens):
• Overview: Init screen
• Setup: Production preparation screen
• Produce: Production screen
• Teach: Create recipe screen
• Statistics: Production related statistics screen
• System: Machine related configuration & calibration screen
• Infopage: Information screen
3
Menu section
The menu and submenu section contains the navigation to processes and
process steps of the appropriate main task.
4
Graphical section The graphical section displays (depending on selected screen):
• machine configuration
• status of initialization and calibration
• PCB
• vision
• parameters (sometimes)
• context help
• tools
• visualization of process and item
5
Parameter section The parameters belonging to the desired screen are displayed in this
section.
6
Softkey section The soft keys belonging to the desired tasks are displayed in this section.
7
Stop, start, help,
lock, feedback
section
This section contains the start and stop production key, the help button
for the context help and the lock/unlock key for the cover.
An additional softkey is for calling the eez-Feedback. In case of wrong
behavior of the machine, by means of this function an e-mail can be sent
to the manufacturer or a zip file can be created.
