Human Machine Interface HMI
3-12 © Essemtec AG Paraquda Startup & Safety
0000003/11 / November 4, 2014
Machine Module States
Overvi
ew
Overview Main
• Parameter 'Initialized' (1)
• Parameter 'Calibrated' (2)
• Parameter 'Mode' (3)
• Graphic Module (4)
State of Machine Calib Mode
Parameter
"Initialized"
Parameter
"Calibrated"
Parameter
"Mode"
Graphic
Module
Before 1st
Initialization
- -
Initialized Yes Real
Not initialized (error)
Yes Real
Initialized No Real
Not initialized (error)
No Real
Initialized Yes Not
Real
Not initialized (error)
Yes Not
Real
Initialized No Not
Real
Not initialized (error)
No Not
Real
