7800/7700 MultiFrame Manual
7814 Series Dual HDTV Up/Down/Cross Converters
Revision 1.1.3 Page - 151
Gamma Level
Sets the gamma correction level. 46
Green Gamma Level
Adjusts the Green Gamma levels. 46
Green Panel
Sets the value for the G component of the background side panels. 71
H Filter Cutoff
Sets the type of the horizontal filter in the scaler. 72
H Slew Limit
Controls sharp horizontal edge transitions. 71
High Knee
This control will set the point at which companding occurs at the
upper range.
47
Hold Time Control
This control is used to set the hold time for the given audio
program.
123
Horizontal Band
Sets the horizontal frequency band. 49
Horizontal Phase Offset
Sets the horizontal phase. 42
Hue
Adjusts the hue of the video signal. +/- 180 degrees in 0.1 degree
increments.
45
Image Enhancement
Enable
Enables the Image Enhancement control settings. 49
In Video Standard
Sets the input video standard to use when designing a user defined
ARC.
61
Input Loudness mode
The Input Loudness Mode control defines the window that will be
used to produce the Input Loudness values in section.
119
Intelligain Gain Adjust X
Sets the value of the gain from the selected source. 112
Intelligain Gain Adjust Y
Sets the value of the gain from the selected source. 114
Intelligain Invert Enable
X
Inverts the phase or passes the selected audio channels. 112
Intelligain Invert Enable
Y
Inverts the phase or passes the selected audio channels. 114
Intelligain Source X
Routes one of the 16 input audio channels to the X input of the
Channel 1 mixer.
111
Intelligain Source Y
Routes one of the 16 input audio channels to the Y input of the
Channel 1 mixer.
113
IntelliGain

State
This control is the master switch for the IntelliGain processor
122
Inverse Telecine
Sets the base type of de-interlacing that the module will perform. 53
Last Line Num in SD
Clean Ap
Defines the last active line for the SD Clean Aperture. 60
Last Line Num in SD
Prod Ap
Defines the last active line for the SD Production Aperture. 60
Last Pixel Num in SD
Clean AP
Defines the last active horizontal pixel for the SD Clean Aperture. 60
Last Pixel Num in SD
Prod Ap
Defines the last active horizontal pixel for the SD Production
Aperture.
60
Leveler Attack Mode
The Leveler Attack Mode defines the maximum integration time that
is applied when loudness increases during a commercial period.
118
