7800/7700 MultiFrame Manual
7814 Series Dual HDTV Up/Down/Cross Converters
Page - 152 Revision 1.1.3
Leveler Release Mode
The Leveler Release Mode defines the maximum integration time
that is applied when loudness decreases during a commercial
period.
119
Leveler State
This control is used to activate the IntelliGain audio leveler
122
LFE Gain
Controls the LFE channel gain after audio is up-mixed. 102
LFE Mixing
Controls whether the LFE channel is included or not in the audio
down-mixing.
94
Loss of AFD Timeout
Configures the action that the converter will take when incoming
AFD signals are lost.
56
Loss of CC Timeout
When video is lost, this control sets the amount of time (in seconds)
before the Closed Captioning timeouts.
133
Loss of Time Code
Control
Set the operation when input timecode is lost. 130
Loss of Video Mode
Selects the action to take when the input video is missing. 42
Low Knee
This control will set the point at which companding occurs at the
lower range.
47
LR_lev
Sets the LR_lev level. 95
Ls_lev_L
Sets the Ls_lev_L level. 95
Ls_lev_R
Sets the Ls_lev_R level. 95
Makeup Gain
The Makeup Gain is used to add additional gain to the audio
program.
124
Max RGB
This control will set the maximum value for the RGB compander. 47
Maximum Gain Control
The Maximum Gain control is the total amount of gain that the
IntelliGain engine will apply.
122
Min RGB
This control will set the minimum value for the RGB compander. 47
Name Control
Sets the name of the user defined aspect ratio conversion. 61
Negative Compression
This control will enable/disable negative colour legalizer
compression to be applied.
48
Noise Floor Threshold
The Noise Floor Threshold control is used to set the threshold level
for IntelliGain processing.
122
Out Video Standard
Sets the output video standard to use when designing a user
defined ARC.
62
Output Gain
Configures the output gain. 94
Output Scaling Mode
Controls whether the down mix matrixing is normalized or not. 93
Peak Limit
The Peak Limit is used within the audio program chain to provide
an upper limit to peak program levels.
124
Source
This parameter defines how the audio channels are grouped
together.
116
R Gain
Varies the Gain in RGB Domain. 45
