7800/7700 MultiFrame Manual
7814 Series Dual HDTV Up/Down/Cross Converters
Revision 1.1.3 Page - 153
Recall Preset
Used to recall a current card configuration from one of the user
presets.
132
Red Gamma Level
Adjusts the Red Gamma levels. 46
Red Panel
Sets the value for the R component of the background side panels. 71
Reference Fail-Over
Set video or free run if valid genlock not present. 128
Reference Select
Set video or external genlock for card locking. 128
RGB Clipper
Enables RGB clipper. 45
Rs_lev_L
Sets the Rs_lev_L level. 95
Rs_lev_R
Sets the Rs_lev_R level. 95
Saturation Gain
Sets the saturation gain level. 45
SD Blanking – 525i/59.94
Last line of blanking in SD for 525/59.94. SD input only. 41
SD Blanking – 625/50
Last line of blanking in SD for 625/50. SD input only. 41
SD CC Source Slecet
Selects which CC shouce to use with SD inputs 132
SMPTE2016-1 Bar
Output Enable
Enables AFD bar output 57
SMPTE2016-1 Output
Enable Control
Enables the insertion of AFD packets in the outgoing video signal. 57
Sets the AFD Output Line level. 57
Soft Clip control will enable/disable the colour compander controls 47
Soft Switch Duration
Sets the upmix soft switch step. 103
Sound Direction Detect
Rate
Controls the detection rate of sound direction. 103
SRC Mode Configuration
Sets mode of sample rate converter. 79
Store User Preset
Used to store the current card configuration. 140
Surround Depth
Controls the depth of surround sound. 102
Surround Phase
Controls whether a 90-degree phase shift is applied to the surround
channels before being passed to the down-mix matrix.
94
T1 To CEA708 Service
Maps closed caption and text channels into CEA708 caption
services.
134
T2 To CEA708 Service
Maps closed caption and text channels into CEA708 caption
services.
134
T3 To CEA708 Service
Maps closed caption and text channels into CEA708 caption
services.
134
T4 To CEA708 Service
Maps closed caption and text channels into CEA708 caption
services.
134
Target Loudness
This control is used to set the target loudness level for the given
audio program.
122
