11. Click on the Move checkbox again.
12. Select the Distance or Angle radio button. In the This Amount textbox, type 195 and
select Degrees from the Units pulldown menu. Select Left from the This direction
pulldown menu.
13. Select the Behavior 3 tab at the top of the screen.
14. Select the Sequence checkbox and select Behavior 2 from the pulldown menu.
15. Select the Move checkbox.
16. Select the Distance or Angle radio button. As before, type 2 in the checkbox. Select
Feet from the Units pulldown menu. Select Forward from the This Direction
pulldown menu.
17. Select the Behavior 4 tab.
18. Select the Sequence checkbox and select Behavior 3 from the Run after pulldown
menu.
19. Select the Move checkbox.
20. Select the Distance or Angle radiobutton. In the This Amount textbox, type 195.
Select Degrees from the Units pulldown menu. Select Right from the This Direction
pulldown menu.
21. Select the Behavior 1 tab.
22. Select the Sequence checkbox and select Behavior 4. This will create a continuous
loop in the behaviors.
23. Click on the Behavior Settings button. The Behavior Settings dialog will
be displayed.
