Selecting and Starting a Test
106 88000 Series
Wireless Test Application
3d. Tap the test block to configure the specific test settings (refer to
page 183). For Dual Port topology, there is a test block for each
port.
3e. For CPRI/OBSAI BERT - Framed L2 in Base Station emulation
mode, tap the clock block
1
to configure the clock synchronization
(refer to Clock on page 167). The clock is automatically set to
Recovered for Remote Radio Head emulation mode.
Note: For Unframed test the clock is set to Internal. For eCPRI BERT framed test
the clock is set to either Internal or External - 1PPS (One-Way
measurement mode).
4. Refer to Test Functions on page 611 for additional test configurations.
5. Tap the Timer tab to automatically start and/or stop the test at a given
time or for a specific duration (refer to Timer on page 368).
6. Tap the Start button from the right navigation bar to start the test (refer
to Start/Stop|TX Button on page 741). The Summary result page will
be automatically displayed when the test is started from any Setup
configuration page. For additional results refer to Test Results on
page 385.
7. When the test ends automatically or is manually stopped, the generate
report pop-up is displayed by default. If required, tap Yes to generate a
report of the test results and statistics (refer to Report Button on
page 731 for more information).
1. Not available in
Dual Port
topology. However the clock is automatically set to
Internal
for the
Base Station
and
Recovered
for the
Remote Radio Head
.
