EXFO Power Blazer - OTN BERT

Test Setup - Test Applications
Power Blazer 53
OTN BERT
OTN BERT
Allows OTN (framed and unframed), OTN multiplexing, and EoOTN traffic
generation with specific test pattern for Bit Error Rate analysis.
 Typical OTN BERT test applications:
 Path/Mapping
The OTN BERT test application offers the following path/mapping
structures depending on the inserted transceiver and enabled options.
Up to OTU4 for 88200NGE/88260 and up to OTU2f for 8870/8880.
Network
under test
Testing Unit DUT Loopback
EXFO Unit
Network
under test
Te st i ng U ni t Te st i ng U ni t
EXFO Unit EXFO Unit
Testing Unit
EXFO Unit
Network
under test
Network
under test
