Test Setup - Test Configurator, Timer, and System
264 88000 Series
Network
Network
From the test menu tap Setup, Test Configurator, the interface block, and
the Network tab.
Note: For Through Mode test application, the Network tab is only available for the
Primary Port but the configured parameters apply to both ports.
MAC
MAC Address indicates and allows changing, when the Factory
Default check box is cleared, the default and unique Media Access
Control (MAC) address given to the Ethernet port.
Factory Default check box, when selected (default), indicates that the
factory source MAC address is used.
Frame Format (layer 2) allows selecting Ethernet II (default) or 802.3
SNAP as the frame format. Only Ethernet II is supported with eCPRI.
IP
IP Version allows the selection of either IPv4 (default) or IPv6. Only IPv4 is
supported for TCP Throughput, RFC 6349, and eCPRI BERT test
applications.
For IPv4 the following configuration parameters are available.
Automatic IP (DHCP) check box, when selected (cleared by default),
allows obtaining an IP address dynamically from a DHCP (Dynamic
Host Configuration Protocol) server.
IP Address
1
: Enter the IP address of the port. The default setting is
10.10.x.y, where x and y are respectively the two least significant bytes
of the port default MAC address.
1. Not configurable when the
Automatic IP (DHCP)
check box is selected.
