Test Setup - Test Configurator, Timer, and System
Power Blazer 303
RFC 6349
RFC 6349
From the Test menu, tap Setup, Test Configurator, and the RFC 6349
block.
Connection
Operation Mode allows the selection of the test operation mode: Dual
Test Set (DTS) or EXFO|Worx Interop.
The connection is graphically displayed with its status as follows:
Operation
Mode
Status Description
Dual Test Set Disconnected No connection established with a remote module.
NAT
LAN/WAN,
WAN IP
Connection established with a remote module.
NAT LAN/WAN and WAN IP indicate presence of NAT
(Network Address Translation) router. The NAT router is
automatically detected and graphically displayed with
LAN/WAN indication as well as the WAN IP address
when the Power Blazer is behind a NAT router.
When there is a NAT at the Remote site, it is required to
create the following rules on this NAT router:
1- for UDP/TCP port 62819 to allow DTS
communication.
2- for the defined TCP port (see TCP Port on page 304).
EXFO|Worx
Interop
Disconnected Verifier not detected (not reachable, invalid IP, or invalid
TCP port).
Ready or
Running
Verifier detected, either running (remote unit locked) or
ready to perform a test.
The detection of NAT (Network Address Translation)
router presence is automatically detected and
graphically displayed. The WAN IP address is also
displayed when the module is behind a NAT router.
Busy Verifier busy with another client (locked).
