Test Setup - Test Configurator, Timer, and System
116 88000 Series
Test Configurator Overview
Test Application indicates the selected test application.
Topology, for Transport Test Applications, indicates the selected
test topology.
Modify Structure button, allows the configuration of the physical
port and the signal interface structure.
Port Status icon and its description for a CFP4/CFP8/OSFP/QSFP
interface is only displayed when validating or if there is a problem
as described in the following table. RequiredForFormatting
Transceiver System Status for a transceiver system is only displayed
when there is a warning or a problem as described in the following
table.
Validating transceiver.
Missing transceiver.
Invalid transceiver or mismatch with the selected signal/interface.
Valid transceiver matching the selected interface/rate. This icon is not
displayed here, it is only displayed for the Physical Interface Port.
Icon Displayed Message Description
Port A/B / Port 1 - The battery for the insertion
counter is low, please contact EXFO Support
The battery is low and must be replaced by an
EXFO authorized service center.
Port A/B / Port 1 - The battery for the insertion
counter is depleted, please contact EXFO Support
The battery is dead and must be replaced by an
EXFO authorized service center.
A1/A2/B1/B2 / Port 1 - Missing TA/TA4 Transceiver
System
No transceiver system detected
A1/A2/B1/B2 / Port 1 - Validating TA/TA4
Transceiver System
Validation process is on-going
A1/A2/B1/B2 / Port 1 - Invalid TA/TA4 Transceiver
System
Validating process completed and incompatibility
has been found
