Getting Started
Power Blazer 17
Inserting and Removing Transceiver System
To remove a transceiver system from the FTBx-88460 module:
1. Position the FTBx-88460 module so
that its faceplate is facing you.
2. Turn the two retaining screws
counterclockwise until they are
loose.
3. Hold the transceiver system by the
handle (NOT by the connectors) and
pull it out.
4. Cover the empty FTBx-88460’s receptacle with the supplied FILLER.
CAUTION
Pulling out a transceiver system by its connectors could seriously
damage both the transceiver system and connectors. Always pull
out a transceiver system by its handle.
CAUTION
Failure to reinstall the FILLER over an empty receptacle will result in
ventilation problems.
