Test Results
596 88000 Series
Traces (OTN)
SAPI OTU/ODU-TIM check box
1
, when selected (cleared by default),
allows editing the expected Source Access Point Identifier (SAPI) and
also enables OTU/ODU-TIM alarm monitoring.
DAPI OTU/ODU-TIM check box
1
, when selected (cleared by default),
allows editing the expected Destination Access Point Identifier (SAPI)
and also enables the OTU/ODU/TCM-TIM alarm monitoring.
Copy RX/Global Copy RX
2
uses the received SAPI/DAPI message as
the expected SAPI/DAPI. For Multi-Channel OTN lower ODU layer, use
the arrow button next to the Copy RX or Global Copy RX to switch
from one button to the other. Global Copy RX uses the current channel
received SAPI/DAPI message as the expected SAPI/DAPI for all
channels while Copy RX only affects the selected channel.
1. For Multi-Channel OTN lower ODU layer, the SAPI and DAPI ODU-TIM check boxes are only configurable from the
test setup.
2. Only available for the lower ODU layer for Multi-Channel OTN and FlexO BERT.
