Test Results
Power Blazer 599
Traces/PT (FlexO)
 SAPI OTU/ODU-TIM check box
1
, when selected (cleared by default),
enables OTU/ODU-TIM alarm monitoring and allows editing the
expected Source Access Point Identifier (SAPI).
 DAPI OTU/ODU-TIM check box
1
, when selected (cleared by default),
enables the OTU/ODU/TCM-TIM alarm monitoring and allows editing
the expected Destination Access Point Identifier (SAPI).
 Copy RX/Global Copy RX
2
uses the received SAPI/DAPI message as
the expected SAPI/DAPI. For lower ODU layer, use the arrow button
next to the Copy RX or Global Copy RX to switch from one button to
the other. However since there is only one client, both Global Copy RX
and Copy RX use the received SAPI/DAPI message as the expected
SAPI/DAPI.
PT (Payload Type)
 Payload Type and Code
Received displays the received payload signal type and its code in
hexadecimal format.
Expected allows selecting the expected payload signal type either by
selecting the payload from the list or by typing its hexadecimal code.
Note: Refer to PT / Global PT on page 379 for the list.
 OPU-PLM
1
, when selected, enables the OPU-PLM alarm analysis.
 Copy RX uses the received payload type as the expected payload type.
1. For the lower ODU layer these check boxes are only configurable from the test setup.
2.
Global Copy RX is only available for the lower ODU layer.
