Test Control
Power Blazer 727
Lpbk Tool Button (Loopback Tool)
S-OAM Responder check box when selected (default) allows
responding to LBM, LTM, DMM, LMM, and SLM valid messages
(Lpbk Tool must be started, see Loopback button below). Traffic
statistics are also monitored (refer to Responder on page 607).
Responder - TX Count reports respectively the count of LBR, LTR,
DMR, LMR, SLR, and the total of frames transmitted.
Responder - RX Count reports counts of valid LBM, LTM, DMM,
LMM, SLM, and the total of frames received. A valid messages must
have its destination MAC address matching either the unit port
Unicast MAC address or a Multicast class 1 address
1
.
Loopback button starts/stops looping back the frames/packets that are
received. The default value is disabled.
Responds to... message Responds with... message
LBM LBR
LTM LTR
DMM DMR
LMM LMR
SLM SLR
1. Refer to
Unicast/Multicast Addresses for Ethernet OAM
on page 841 for more information.
