Test Control
730 88000 Series
Lpbk Tool Button (Loopback Tool)
Flow Control choices are TX, RX, RX and TX, None (default), and
Auto
1
. When the Flow Control is set to None, pause frames received
are ignored.
Cable Mode is available with 10/100/1000M Electrical interface.
Manual mode is selected when the Auto-Negotiation check box is
cleared and allows selecting the type of cable: MDI (default) for
straight through cable or MDIX for crossover cable.
Automatic mode is selected when the Auto-Negotiation check box is
selected and allows detecting automatically the MDI or MDIX cable
type.
Local Clock is only available with 1GE electrical interface and allows
setting the provenance of the clock: Master (default), or Slave, or
Auto
1
.
Network tab
Refer to Network on page 264 for more information.
SFP/SFP+ tab
Refer to CFP/OSFP/QSFP/SFP on page 164 for more information.
1.
Auto
is only available when the
Auto-Negotiation
check box is selected.
