Test Setup - Test Applications
Power Blazer 69
EtherSAM (Y.1564)
 Typical EtherSAM (Y.1564) test applications:
 Supported Interfaces/Rates: 10M to 10G LAN/WAN, 40G and 100G. Dual
Port topology is only available for rates up to 10G WAN.
Network
under test
Testing Unit Loopback Unit
EXFO Unit EXFO Unit
Network
under test
Testing Unit Remote Unit
EXFO Unit EXFO Unit
Network
under test
Testing Unit
EXFO Unit
