Extron electronics SMP 300 Series User Manual

SMP 300 Series • Front Panel Operations 36
Record To (Internal + 2nd)
The Record To submenu selects the drive the input records to. Selecting Internal + 2nd
assumes there is a USB drive connected. The input is always recorded to both the internal
and external drives.
NOTE: In Dual Channel mode, Secondary Recording is disabled.
• Internal — Displays the available drive space for the internal drive.
• External — Displays the available drive space of the connected USB drive. If no drive
is currently connected, the drive space shows N/A.
When External is active, rotate the left ([) ADJUST knob to select from the following:
• <USBFRONT [VOLNAME]> — An external drive connected to the front panel USB port.
• <USBREAR [VOLNAME]> — An external drive connected to the rear panel USB port.
• <USBRCP [VOLNAME]> — An external drive connected to the RCP USB port.
Streaming
Streaming is available in both archive and confidence encodes. Streaming can be ON
(enabled) or OFF. When streaming is enabled, the STREAM METHOD, STREAM PROTOCOL, and
MULTICAST IP or DESTINATION IP submenus are available (see figure21). The appropriate
submenus are displayed depending on the previous submenu selection.
NOTE: In the menus and submenus, MULTI refers to a multicast protocol and UNI
refers to unicast.
MENU
NEXT
NEXT
RECORD/STREAM
CONFIGURATION
Rotate either to
toggle streaming
on or off.
STREAMING
<ON>
- OR -
-OR-
NEXT
NEXT NEXT
NEXT
Rotate either to
select RTSP PULL, RTP
PUSH, or RTMP PUSH.
Rotate [ to select octet.
Rotate { to change address.
Rotate [ to select octet.
Rotate { to change address.
Press NEXT to select and move
to next submenu.
Rotate either to select protocol.
Press NEXT to select and move
to next submenu.
STREAM PROTOCOL
<UNICAST>
STREAM PROTOCOL
<UNICAST>
STREAM METHOD
<PUSH>
STREAM METHOD
<RTSP PULL>
DESTINATION IP
XXX.XXX.XXX.XXX
MULTICAST IP
XXX.XXX.XXX.XXX
STREAM PROTOCOL
<MULTICAST>
Rotate either to select protocol
from this list:
UNI TS/UDP MULTI TS/UDP
UNI TS/RTP MULTI TS/RTP
UNI ES/RTP MULTI ES/RTP
NEXT
Figure 21. Streaming Submenus
The following submenus appear only when the encoder selection is ARCHIVE. Confidence
encodes have independent stream settings.
21
