Detector III
Typical for a new machine.
Condition of machine is suitable for continuous operation.
Condition of machine is no longer suitable for continuous operation;
limited operating duration possible in this state.
Hazardous vibrational state, damage to the machine may be
imminent.
(Source: ISO 10816-1)
Components of motors and machines rigidly connected with the complete machine
under the usual operating conditions (typical: drive motor up to 15 kW output).
Medium-sized machines (typical: 15 kW to 75 kW output) without special foundations,
rigidly constructed motors and machines (up to 300 kW) on special foundations.
Large motors and other large machines with rotating masses, constructed on rigid and
heavy foundations that are relatively stiff in the direction of the vibration that is
measured.
Large motors and other large machines with rotating masses, constructed on foundations
that are relatively forgiving in the direction of the vibration (e.g. turbo generating sets and
gas turbines with an output greater than 10 MW).
Select Single measurements > ISO 10816 and then the desired class.
The measurement is performed accord to the CM measurement . Finally a
summary of the results including the alarm status is displayed. The
demodulation value is shown without alarm status.
