Trendline 3
Menu
Menu items and function
databases
You can specify the number in the program settings .
Close
Quits the Trendline software.
System
To root level
Takes you from your current position in the tree right back to the
beginning, all the time.
Rename
Rename currently selected element.
New item
Inserts an element of the configuration structure in the same level as
currently displayed.
New sub-item
Inserts an element of the configuration structure in the level below the
current.
Add balancing
configuration
Inserts a balancing configuration.
Add amplitude/
phase configuration
Creates an amplitude/phase configuration.
Add run up / coast
down configuration
Creates a run up/coast down configuration.
Expand selection
Flaps up all elements under the current element.
Collapse selection
Closes the complete tree structure.
Cut
Cuts out the current element of the tree.
Copy
Copies the current element of the tree.
Paste
Pastes the element on the clipboard into the current position in the
tree. This is only possible in the tree level above that of the copied
element. For example, when copying a machine, this can only be
pasted into the plant level of the tree.
Delete entry
Deletes the current entry in the tree with all sub-entries.
Delete measured
data
Deletes measured data from the current position.
Reset alarm status
Reset all alarms for the element of the configuration and system
structure selected.
Adjust alarm limits
Automatic adjustment of the alarm limits.
Save configuration
as template
Saves a configuration as template so that it can be used for free
measurements.
Create new
configuration from
template
Creates a new configuration from a template.
Detector
Send configuration
Send all measuring points from currently selected element
downwards to Detector.
