Appendix 3 Interpretation of Wiring Connection between F2000 Series and Common THC
124
5
4
3
2
1
17
16
15
14
F2000 Series CNC
Output port
6
18
13
6
2
1
25
18
14
Input port
13
25
4
16
AUTO Auto signal
UP Up signal
DOWN Down signal
IHS_ARCON Arcing signal with original position
DIR_ARCON Immediately arcing signal
TRANSFER1 Pierce finished signal
TRANSFER2 Pierce finished signal
COM Common port of control signal
COLLISION Collision feedback signal
1
2
3
4
5
6
7
8
9
10
PE shield layer of signal wire
F1630 THC
TO CNC
