FangLing F2500(A/B) - Input Wiring Instructions

Chapter 11 Port Explanation
90
11.1.1 Input Wiring Instructions
1
Right limit
14
2
15
3
16
4
17
5
18
6
19
7
20
8
21
9
22
10
23
11
24
12
25
13
Left limit
Front limit
Back limit
Emergency Stop
Arcing
successfully
Positioning
successfully
Plasma collision
ignition
Cutting oxygen
Torch up
Torch down
Move left
NC
Move right
NC
Move ahead
NC
Move backward
NC
NC
+24V
+24V
24VG
24VG
com
Right limit input
Left limit input
Front limit input
Back limit input
Emergency
stop input
Arcing
successfully
feedback
Positioning
successfull
y feedback
Plasma collision feedback
1.For Plasma cutting
2.Accessed when CNC positioning is
needed. And positioning successfully
input should be configured as
normally open type. Or it can be not
accessed when using height adjusting
device to positioning.
3.When plasma collision detection is
needed, accessed to plasma collision
feedback.
Caution: All inputs can be
normally closed or normally
open, and all inputs are
normally open in defualt.
（connecting to 24VG of the
system or connecting to the 24VG
of the external 24V switching
power supply.）
Fig 11.2 External input wiring
