FangLing F2500(A/B) - 10.4 M Code Explanation

Chapter 10 Code Explanation
86
 Y – rotate angle, can be set from -360° to 360°.
 I – image of X axis, make image along X axis, 1 expresses that there is image, 0
expresses that there is no image.
 J –image of Y axis, make image along Y axis, 1 expresses that there is image, 0
expresses that there is no image.
Note:
A code can have G99, also cannot. If there is G99, the parameter X, Y, I, J after code
should not be ignored. Mirror image and rotation will take the origin (0, 0) of Descartes
coordinate as reference point.
10. Program notice items
 The program must contain the instruction of G92 (reference point setting) and
M02(end of program).
 G41/G42 must match with G40 to be used. If G41/G42 is ignored, the default kerf
compensation is zero; if G40 is ignored, kerf compensation is available.
 If G20 / G21 is ignored, the system will execute G21 (metric unit).
 If G90 / G91 is ignored, the system will execute G91 (relative coordinate).
 M07 and M08 can’t be neglected.
 When there is one parameter in the code of G00、G01、G02、G03 is ignored, if this
parameter is absolute coordinate, the system will set it G code coordinate value of last
row; If it’s relative coordinate, the system will set it 0.
 G00、G01、G02、G03 can be simplified: G0、G1、G2、G3.
 If there is contiguous G00 (or G01、G02、G03) around, the following G00 (or G01、
G02、G03) can be ignored.
10.4 M Code Explanation
Table 10.3 Common M code
M07 No parameter Cutting device on
M08 No parameter Cutting device off
M00 No parameter End of instruction
M02/M30 No parameter End of program
 M07 Cutting device on
Please refer to Appendix 2 I/O Timing Sequence Figure of F2000 Series Numerical
Control System.
 M08 Cutting device off
Please refer to Appendix 2 I/O Timing Sequence Figure of F2000 Series Numerical
