Chapter 8 Diagnosis Function
68
F1 Input F2 Output F8 Save
definition of input
forward limit 02
back limit 15
left limit 14
right limit 01
emergency stop 03
arcing feedback 04
Position detect 05
Plasma Collision 06
Move up input 09
Move down input 10
Move left input 07
Move right input 08
Acceleration input 16
Deacceleration input 17
Torch up input 18
Torch down input 19
F3 Axes F4 Motor
Port Type
Port Type
Port- press PgUp/PgDn Type-press Enter
F5 Option
Fig 8.8 input definition
In the interface press 【↑】、【↓】、【←】、【→】, move the cursor to the position that
needs changing, press 【PgUp】or【PgDown】to change the number of the Input, press
【Enter】to change the type of the input.
If the external type of input is normally closed, please set the IO type to ●, if the
type is normally open, please set the IO type to ●.
8.7.3 Output Definition
The controller could change the IO definition, including changing the order of IO
number, the type of IO( normally open or closed) according to the user’s need. In the
system custom definition interface, press 【F3】 to enter the definition interface, press
【F1】to enter the input definition interface. As shown in fig 8.9.
