Chapter 8 Diagnosis Function
71
8.7.5 Motor
F8 SaveF2 Output F3 AxesF1 Input F4 Motor F5 Option
Horizontal direction CW
▌
Vertical direction CCW
XY exchange No
Press Enter to change.
Fig 8.11 Motor direction
Press up or down key, move the cursor ▌to the axes of which needs to change motor
rotation direction, then press 【Enter】, the motor direction can switch between positive
and reversal.
XY exchange: if this function is “YES”, output pulse of X axis and Y axis exchange
each other, in other words, horizontal axis and vertical axis exchange each other.
