FangLing F2500(A/B) - 7.5 System Parameters

Chapter 7 Parameter Setting
57
F1 Common F4 PowderF2 Flame F8 Save
Marker Ignition Time 0.00 s
Marker Preheat Time 0.00 s
Mix powder Open Time 0.00 s
Mix powder Close Time 0.00 s
Marker Up Time 0.00 s
Marker Down Time 0.00 s
Marker Horizontal Offset 0.000 mm
Marker Vertical Offset 0.000 mm
F3 Plasma F5 System F7 ExportF6 Import
Fig 7.5 powder parameters
 Marker Ignition Time：Input ≥0 arbitrary value, unit: s.
 Marker Preheat Time：Input ≥0 arbitrary value, unit: s.
 Mix powder Open/Close Time：Delay time of scatter powder mouth relative to spurt
powder mouth open/close, input ≥0 arbitrary value, unit: s.
 Marker Up Time：The time of powder torch going up. Unit: s.
 Marker Down Time：The time of powder torch going down. Unit: s.
 Marker Horizontal Offset：Horizontal offset of powder gun relative to cutting torch.
Unit: mm.
 Marker Vertical Offset：Vertical offset of powder gun relative to cutting torch. Unit:
mm.
7.5 System Parameters
The system parameters, as shown in Fig 7.6, are related with the precision of driver
shaft of the cutting machine, coordinate axis, increase/decrease of rate and little arc
processing limited parameter.
