Chapter 8 Diagnosis Function
69
F1 Input F2 Output F8 Save
definition of output
F3 Axes F4 Motor
Port Type
Port Type
Port- press PgUp/PgDn Type-press Enter
F5 Option
Ignition 01
Low preheat 01
High preheat 01
Low Oxygen 01
Medium Oxygen 01
High Oxygen 01
Torch up 01
Torch down 01
Blow 01
THC enable 01
Position detect 01
arc starting 01
HoldTorch 01
Marker Output 01
Mix powder 01
dust preheat 01
Fig 8.9 output definition
In the interface press 【↑】、【↓】、【←】、【→】, move the cursor to the position that
needs changing, press 【PgUp】or【PgDown】to change the number of the Output, press
【Enter】to change the type of the Output.
The output type is open drain transistor output type.
Type ● means that if the output signal is effective, the transistor is on. Type ●
means that is the output signal is effective, the transistor is off.
8.7.4 Coordinate Definition
The system could provide IO definition for the user. As shown in Fig 8.10
