FangLing F2500(A/B) - Page 44

Chapter 4 Part Option
35
The result is shown in figure 4.11:
F4 Scale
F5
SelLinePierce
F6 EditFile F7 Revert
FLSK F2200T
Version 3.3.71.1
Speed:
00000
File:
SHAPE_43.TXT
Status:
Stop
Current Line/Hole:
00000/00000
+X:500.00 -X:0.00 +Y:500.00 -Y:0.00
X：+000000.0
Y：+000000.0
1:（TEST PATTERN）
2：G92
【X】 Xmirror
【Y】 Ymirror
CutSpeed 【X】1000.00 Kerf【N】1.20
ManualSpeed【Y】3000.00 Angle 0.00
Manual 【F】 keepMov
StepDis【G】 5.00 Flame Cu 【M】
F1
StartPoint
F2 Angle F3 Array F8 OK
Fig 4.11 Result of staggered arrangement
Press [F3] to enter arrangement in stack:
F3 Array F4 Scale
F5
SelLinePierce
F6 EditFile F7 Revert
FLSK F2200T
Version 3.3.71.1
Speed:
00000
File:
SHAPE_43.TXT
Status:
Stop
Current Line/Hole:
00000/00000
+X:500.00 -X:0.00 +Y:500.00 -Y:0.00
X：+000000.0
Y：+000000.0
1:（TEST PATTERN）
2：G92
【X】 Xmirror
【Y】 Ymirror
CutSpeed 【X】1000.00 Kerf【N】1.20
ManualSpeed【Y】3000.00 Angle 0.00
Manual 【F】 keepMov
StepDis【G】 5.00 Flame Cu 【M】
Enter parameter(unit mm)
rows 2 Cols 2
RowSpc 500.00 ColSpc 500.00
RowNest 500.00 ColNest 500.00
F8: OK
F1
StartPoint
F2 Angle F8 OK
Fig 4.12 Arrange in Nest
