Chapter 9 Graph Management
78
F1 Inside F8 OK
1
2
Lead in
Lead In 10.00
Lead Out 10.00
Size 1 100.00
Size 2 100.00
res=1,L/C apart
Lead out
F2 Outside
Fig 9.3 Hole size
Modify sizes like modify chip sizes.
After modification , press 【F8】to confirmed, then enter into the interface of cutting
as shown in Fig 3.1.
Note: The graphic after No.29 don’t have hole size.
