Printing a Test Image
Step Procedure
1
Choose Print Test Image to select a preset test image. (Note: These images
help to determine if the Printer is functioning properly.)
2
Scroll to the desired test image from the Select Test Image options and press the
Select button.
Reviewing the Gray/Align YMC/K Self-Test
Step Procedure
1 Use this card to determine Image Placement and confirm that the Printer is
working properly. See Printer Adjustments. (Note: The image consists of sixteen
(16) gray scale boxes and alignment arrows. The gray boxes are composed from a
composite of YMC color panels.)
