RESTRICTED USE ONLY Fargo Electronics, Inc.
HDP600 High Definition Card Printer/Encoder User Guide (Rev. 2.3)
7-4
IMPORTANT! Fargo Card Printers require highly specialized Print Ribbons to function
properly. To maximize Printer life, reliability, printed card quality and durability, you must use
only Fargo Certified Supplies. For this reason, your Fargo warranty is void, where not
prohibited by law, if you use non-Fargo Certified Supplies. To order additional materials,
please contact your authorized reseller.
Adjusting the Card Size
The Printer is only configured to feed and print standard CR-80 sized cards. (Note: When
loading cards which vary from the standard 30 mil thickness, it is necessary to make simple
adjustments to the Printer.)
Wider Cards: HDP600 does not accommodate wider loads. Please consult with your
Fargo sales representative if you have wider card needs.
Thicker or Thinner Cards: If loading thicker or thinner cards into the Printer, adjust the
Card Thickness Adjustment Lever.
Adjusting the Card Thickness Adjustment Lever
When loading thicker or thinner cards, it is important that the Card Thickness Adjustment
Lever be set accordingly to ensure the Printer feeds only one card at a time. (Note: If the
Printer is equipped with the Card Lamination Module, only cards with a thickness ranging
from 30 mil to 40 mil can be laminated. Thicker cards will, however, be allowed to pass
through the Lamination Module if you choose to print-only.
Step Procedure
1 Open the Printer's Card Access Door and locate the Card Thickness
Adjustment Lever.
2 Press the blue lock and raise or lower the Lever to the setting that matches the
thickness of the cards. (Note: If you do not find a setting for the exact card
thickness, set the adjustment knob to the setting closest to the thickness of the
cards.)
The adjustment level controls the position of the Printer's internal Card
Separator, which is designed to accommodate a range of card thicknesses
surrounding the given card thickness settings.
