Additional Procedures
Reviewing LED and Dipswitch Tables
The LEDs and dipswitches can be found on the back of Printers.
Reviewing the LED Table
LED HDP600
position
Flash Rate Indicates
On once per second
(i.e., more OFF than ON)
The Normal Mode, IP address is
configured.
On twice per second The IP address is not configured.
Off once per second
(i.e., more ON than OFF)
The Download mode is for updating the
Ethernet interface.
STAT
LED
Right
Off twice per second There is a system error.
On The Network link is present.
Off The Network link is not present.
NET
LED
Left
Blinking, off 1/3 second The Network link is present and
transmitting. It flashes off for one-third
(1/3) second each time a packet is
transmitted.
