RESTRICTED USE ONLY Fargo Electronics, Inc.
HDP600 High Definition Card Printer/Encoder User Guide (Rev. 2.3)
2-7
Technical Specifications
Term Description
Accepted
Standard Card
Sizes
HDP600 and HDP600-LC (See Card tab under Printer
Adjustments):
CR-80: This selection is the default form size for the HDP600.
This will print a 3.375 in. L x 2.125 in. W (85.6mm L x 54mm W)
image including a .04 over-bleed on each of the 4 sides. This
makes the overall form size 2.204 X 3.452 (56 X 87.7 mm).
CR-80 No Over-Bleed: This selection eliminates the over-
bleed on both the leading and trailing edge making the form size
of 3.374 in. L x 2.2 in. W (85.7mm L x 56mm W). Note: This
selection is used to improve the overall readability of barcodes.
Custom: This selection is used to create a custom form size
from 1.0 x 3.0 to 2.204 to 3.452 (25.4 X 76.2 mm to 56 X 87.7
mm).
HDP600 CR100 and HDP600-LC CR100 (same reference):
CR-100: This selection is the default form size for the HDP600
CR100. This will print 3.88 in. L x 2.63 in. W (98.5mm L x 67mm
W) including a .04 over-bleed on each of the 4 sides.
This makes the overall form size 3.92 in. L x 2.67 in. W
(98.9mm L x 71mm W). The CR-100 size PolyGuard applies
only if laminating with HDP600-LC CR100.
CR-100 No Over-Bleed: This selection eliminates the over-
bleed on both the leading and trailing edge making the form size
of 3.88 in. L x 2.63 in. W (98.5mm L x 67mm W). (Note: This
selection is used to improve the overall readability of barcodes.)
Custom: Select the Custom option under Card tab in the
Printer Driver. Enter the dimensions of the card into the Print
Width and Print Length boxes if using a card size that varies
from the CR-100. Add .04" (1mm) to each dimension to ensure
Edge-to-Edge printing.
