RESTRICTED USE ONLY Fargo Electronics, Inc.
HDP600 High Definition Card Printer/Encoder User Guide (Rev. 2.3)
8-11
Cleaning the Transfer Rollers using the Cleaning Card
Step Procedure
1 Leave the Printer power ON and open the Lamination Arm.
If using a Printer with a Card Lamination Module attached, also open the
Lamination Module's Top Cover and Lamination Station.
2 Remove the cards from the hopper but leave the Print Ribbon and HDP Film
and the Cleaning Cartridge in the Printer
3 Remove the paper from the adhesive side of the Cleaning Card.
4 Insert the cleaning card into the cards hopper with the sticky side UP.
Caution: Do not insert the card with the sticky side DOWN or it will
stick to the card path.
5
Danger: Transfer Rollers will be extremely hot. Ensure that the
Printer is cold before cleaning it.
a. With the Cleaning Card inserted correctly into the hopper, press the
Forward and Back buttons to move the Roller back and forth while
cleaning.
b. If using a Printer with a Card Lamination Module (attached), run this card
through the Lamination Transfer Roller as well.
c. Eject this card through the Output side of the Printer.
7 Replace the printing supplies and close the Print and Transfer Stations.
